TOKYO--(BUSINESS WIRE)--Mar 24, 2014--Toshiba Corporation (TOKYO:6502) today announced the launch of “TB67H303HG”, a one-channel DC brush motor driver IC for industrial equipment. The product is the industry’s first 1 monolithic 2 IC to realize 10A output current and 50V withstand voltage. Mass production shipments start today.
Toshiba: "TB67H303HG", the industry's first monolithic DC brush motor driver IC realizing 10A output current and 50V withstand voltage (Photo: Business Wire)
High output current and voltage are required for motor driver circuits in industrial equipment. That makes it difficult to design circuits with a single driver IC, as the high current generates heat. Multiple discrete semiconductors are generally used in order to reduce heat generation in each component.
“TB67H303HG” adopts the latest high voltage analog process, reducing on resistance to 80% that of its predecessor 3, to 0.2Ω or less. The new IC contributes to the reduction of discrete semiconductor devices, and to simplification and downsizing of applications.
The IC also incorporates abnormality detection functions, contributing to improved safety for high current motor drive.
Key Features
Driving mode Selectable from two driving modes: standard direct PWM mode, or newly adopted constant current PWM mode. High current drive Low on resistance of 0.2Ω or less (sum of upper and lower) realizes absolute maximum output current of 10A. Built-in abnormality detection functions Incorporates a thermal shutdown circuit, over current detection, and undervoltage lockout (UVLO) circuit, which improve the safety of the high current motor drive. Applications
Industrial equipments, banking terminals such as banknote recognition systems, home appliances including sewing machines, and office automation equipment.
Notes: 1: Survey by Toshiba Corporation, as of March 24, 2014. 2: One chip is used in one package. 3: Comparison with “TB67H400AFTG”
Customer Inquiries: Mixed Signal IC Sales and Marketing Department Tel: +81-44-548-2821
Information in this document, including product prices and specifications, content of services and contact information, is current on the date of the announcement but is subject to change without prior notice.
About Toshiba
Toshiba is a world-leading diversified manufacturer, solutions provider and marketer of advanced electronic and electrical products and systems. Toshiba Group brings innovation and imagination to a wide range of businesses: digital products, including LCD TVs, notebook PCs, retail solutions and MFPs; electronic devices, including semiconductors, storage products and materials; industrial and social infrastructure systems, including power generation systems, smart community solutions, medical systems and escalators & elevators; and home appliances.
Toshiba was founded in 1875, and today operates a global network of more than 590 consolidated companies, with 206,000 employees worldwide and annual sales surpassing 5.8 trillion yen (US$61 billion). Visit Toshiba's web site at www.toshiba.co.jp/index.htm
